ASP-103612-04

Name: Samtec ASP-103612-04
Brand: Samtec
SKU: 200-ASP-103612-04
Price: 693662 IDR
Availability: InStock

Images are for reference only
See Product Specifications

Mouser No:

200-ASP-103612-04

Mfr. No:

ASP-103612-04

Mfr.:

Samtec

Description:

Board to Board & Mezzanine Connectors ASP

Datasheet:

ASP-103612-04 Datasheet (PDF)

ECAD Model:

Download the free Library Loader to convert this file for your ECAD Tool. Learn more about the ECAD Model.

More Information

Learn more about Samtec ASP-103612-04

In Stock: 73

Stock:: 73

Can Dispatch Immediately

An unexpected error occurred. Please try again later.
On Order:: 1.350

675

Pending

675

Expected 09/03/2026
Factory Lead Time:: 1

Week Estimated factory production time for quantities greater than shown.

Enter Quantity:

Minimum: 1 Multiples: 1

Unit Price:

Rp-

Ext. Price:

Rp-

Est. Tariff:

Packaging:

Full Reel (Order in multiples of 675)

Cut Tape

MouseReel™ (+Rp98.000)

Pricing (IDR)

Qty.	Unit Price	Ext. Price
Cut Tape / MouseReel™ ^†
	Rp693.662	Rp693.662
	Rp621.379	Rp6.213.790
	Rp582.119	Rp14.552.975
	Rp490.572	Rp24.528.600
	Rp444.157	Rp44.415.700
	Rp402.144	Rp100.536.000
Full Reel (Order in multiples of 675)
	Rp381.964	Rp257.825.700

† A MouseReel™ fee of Rp98.000 will be added and calculated in your basket. All MouseReel™ orders are non-cancellable and non-returnable. ↩

.hidden-for-nojs { display: none; } .pull-right-nojs { justify-content: flex-end; }

Product Attribute	Attribute Value	Select Attribute
Manufacturer:	Samtec
Product Category:	Board to Board & Mezzanine Connectors
RoHS:	N
Product:	Sockets
Number of Positions:	114 Position
Pitch:	1.27 mm (0.05 in)
Number of Rows:	6 Row
Termination Style:	Solder Balls
Mounting Angle:	Straight
Stack Height:	10 mm
Contact Plating:	Gold
Contact Material:	Phosphor Bronze
Series:	ASP
Packaging:	Reel
Packaging:	Cut Tape
Packaging:	MouseReel
Brand:	Samtec
Flammability Rating:	UL 94 V-0
Mounting Style:	SMD/SMT
Product Type:	Board to Board & Mezzanine Connectors
Factory Pack Quantity:	675
Subcategory:	Board to Board & Mezzanine Connectors
Tradename:	SEARAY
Unit Weight:	5,058 g

Products found:

To show similar products, select at least one checkbox

Select at least one checkbox above to show similar products in this category.

Attributes selected: 0

Filter Document:

CNHTS:: 8536901100
CAHTS:: 8536690020
USHTS:: 8536694040
JPHTS:: 853669000
KRHTS:: 8536691000
TARIC:: 8536693000
MXHTS:: 8536699999
BRHTS:: 85366990
ECCN:: EAR99

Industry Standards Solution

Samtec's Industry Standards Solution improves compatibility, performance, and efficiency. Samtec provides connector products that interact with many types of hardware and software. This drives the need to adhere to a variety of Industry Standards.

VITA 42- SamArray XMC Standard Connectors

Samtec VITA 42-SamArray XMC Standard Connectors are solder ball-equipped SamArray connectors available in 10mm and 12mm stack heights. The solder options include lead-free and tin-lead alloys. These Samtec connectors follow VITA 42 XMC, a widely deployed mezzanine standard used in high-reliability computers implementing switched-fabric architectures. The XMC standard combines PCI Mezzanine Card (PMC) with serial fabric technology on a proven mezzanine form factor. The VITA updated XMC's base specification to recommend solder ball connectors. These original parts employed paste-on-pad attachment, and recommended parts utilize modern solder ball technology.

Flexible Stacking Connectors

Samtec Flex Stacking Board Connectors feature a large variety of board-to-board connectors with design flexibility. These Samtec board-to-board connector systems are available in a variety of pitches, densities, stack heights, orientations, and other standard or modified options, making it easy to find the right connector for any application. Flex-Stack options include one-piece, low profile pass-through, elevated, hermaphroditic, shrouded, coplanar, parallel, and perpendicular. Post heights are adjustable in increments of 0.005” (0.13mm).
